Roller Blinds
installation guide

Installing roller blinds was never so easy

We aim to provide you with straightforward and easy-to-follow instructions for installing your personalized Roller Blinds. Your custom kit has been specifically designed to be incredibly user-friendly, allowing you to enjoy the process of effortlessly clicking, sliding, and securely locking the components together.

Tools you’ll need to install

  • Saw
  • Drill
  • Drill bits (2.5mm, 2.6mm, 3mm, 3.2mm, 4mm, 6mm, 10mm)
  • Screw Driver
  • Scissors
  • Measuring Tape
  • Spirit Level
  • Laser Level/ Lease measuring device
  • Silicone gun/ gap fillers/ packers

PART A – Preparing Installation

Step 1

Check for any obstructions that may interfere with the installation.

E.g. If there is an architrave at the bottom of the post that the blind is to be installed into, ensure you prepare the space for the installation of the guides. This may mean the installer needs to cut into the architrave to make room for the side rails.

Step 2 – Check top of the installation is level

If uneven, go to step 3.

If level, go to step 4.

Step 3 – Pack and level to of installation to smallest drop dimension

Ensure the box fits in the smallest measurement (TOP) and ensure the box will be level the whole way across – flashing can fill the gap once installed.

NOTE

In some instances when the drop is level on either side the ground may be uneven.
Ensure the box/brackets are installed at the smallest measurement (DROP).

Step 4 – Check horizontal installation dimension at the top, centre and bottom

Once checked if all width measurements are equal or within 10mm of each other, proceed to step 5 for side fix applications or step 6 for face fit applications. If all widths are not equal or within 10mm of each other you will need to determine where packing is required.

Step 5 – Pack installation width to blind width measurement

If all widths are less than 10mm out of square no packing is necessary, however, being completely square will provide greater flexibility with the rest of the installation.

If all widths are more than 10mm out of square packing is required. Rule of thumb – pack centre and bottom measurements out to sit square with the top measurement. This is the measurement that you measured for the box.

Proceed to step 6 for side fix applications or step 7 for face fix applications.

Step 6 – Check sides of the installation are level
(side reveal fix applications only)

If all widths are less than 10mm out of square no packing is necessary, however, being completely square will provide greater flexibility with the rest of the installation.

Ensure both sides are square between posts (or wall). If measurements are equal or greater than the top measurement packing is required.

Ensure the widths are equal from the top down.

Step 7 – Check and ensure the installation space is level and square

Run your tape across all measurements both width and height and ensure all is level and square. If anything is out slight adjustments with packers are required.

Fit the hood / Universal brackets in between or on the face of the structure, depending on the application.

PART B – Spring pre-tensioning

Identify number of pre-turns required for blind size

For spring-loaded E-Zip Blinds.
Smaller blinds > 12 turns on the spring.
Larger blinds (bigger than 2000mm) > 16 turns.

You will feel the spring compressing. Normally, smaller blinds are installed with 13 turns on the spring and larger blinds are installed with 18 turns. Ensure you lock the spring once spun. This will make sure the spring does not let go whilst installing the blind.

Follow the directions on the spring side for tightening or loosening, + or -.

PART C – Box installation

Install box to wall/ceiling/post (pelmet)

Using the appropriate fixings to suit the application. Ensure all endplates and boxes are aligned and level and then finally measure the box end to end to ensure the measurement is correct.

PART D – Open bracket installation

Install bracket to wall/ceiling/post

Using the appropriate fixings to suit the application ensures the brackets are aligned and level. Screw them in and then measure brackets end to end to ensure the measurement is correct.

PART F- Side guide installation

Mark out side guide position and align rail

Fit the outer c-channel and line the back of the channel up with the back of the hood/Universal brackets, for a face fit you will need an angle to fit the c-channel off. Slide the black nylon into the inner side channel and slot it into the fitted c-channel.
Line up the inner channel/nylon under the edge of the zip and guide the zip into the nylon. (One side at a time if fitting by yourself or both at the same time if it’s a two-person job).

PART E – Blind installation

Step 1- Install blind into box

An effort is required when inserting the blind and the axle into the box/brackets.
A noticeable click will indicate the component is correctly located.

Spring loaded – Unlock the pre-tension head at the spring end.
Motorised – Feed through motor cable either through the pre-drilled hole at the top or back of the box.

Step 2- Run blind down + centre & test operation

Ensure the blind is central on the axle. Run the blind up and down and make sure all runs smoothly.

PART G – Adjusting inner channel

Step 1- Operate blind to straighten fabric

Run the skin up and down before fixing the inner channel to make sure the blind is going up and down straight. This will also ensure that the inner channel falls into its natural position.

Step 2- Fixing inner channel

Run the blind down to the bottom of the tracks and fix the inner side channel to the c-channel with self-drilling wafer screws, one side at a time while testing the blind. Use these as you may need to adjust.
It’s important that you test the blind each time you fix a screw through the channels. You will need to fix the channels at the top, middle & bottom to ensure fabric tension is perfect.

NOTE

If the blind is motorised or spring, you will need to fit off stoppers at the top of the inner channel to ensure the blind doesn’t come out of the top of the nylon. These will be supplied and are to be riveted into the inner channel about 20mm from the top and 10mm in from the outside edge.

Well done, you did it

What do you think about sharing a photo of your project and tagging us?

Thanks for choosing Shutters4U.

If you still have any questions, please give us a call or send us a message
