Roller Shutter Guides
Comprehensive Roller Shutter Guides with everything you need to know about parts, mounting methods, controls, measuring, and installation tips.
Installation guide
Roller Shutter Guides
Parts of a Roller Shutter
Ensure you understand the key parts of a roller shutter by looking at the components below before making your selection.
Comprehensive Roller Shutter Guides with everything you need to know about parts, mounting methods, controls, measuring, and installation tips.
Header Box
Roller Shutter Guides
This is the box at the top of the roller shutter that stores the shutter when it is retracted and not in use. It contains the motor that operates electric (mains-powered) or battery-powered shutters and contains the axle around which the shutter is wound. All header boxes have a square profile and are made from 0.9mm gauge high-grade aluminium.
Slats
Roller Shutter Guides
These are the individual slats that form the protective curtain over the window. All our slats are made from a double-walled aluminium cavity and which is then injected with a 9mm polyurethane foam, which provides superior insulation and noise reduction.
Slats
Roller Shutter Guides
These are the individual slats that form the protective curtain over the window. All our slats are made from a double-walled aluminium cavity and which is then injected with a 9mm polyurethane foam, which provides superior insulation and noise reduction.
Guide Rails
Roller Shutter Guides
These are the high-strength aluminium channels at either side of the modern roller shutter which keep the slats in place and support the header box. Guide rails are always colour-matched with the header box for maximum visual appeal.
Bottom Bar
Roller Shutter Guides
If your window lacks a sill, it is recommended to utilize a bottom bar to halt the Shutters when they reach the bottom of the window.
Bottom Bar
Roller Shutter Guides
If your window lacks a sill, it is recommended to utilize a bottom bar to halt the Shutters when they reach the bottom of the window.
Roller Shutter Guides
Mounting Methods
Before you take any measurements, you need to decide whether you want the roller shutter mounted on the wall or mounted inside the reveal/recess of the window. See the pictures below for illustrations.
Mounted on wall
This is one of the simplest ways to measure and fit DIY roller shutters. With this type of fixing the header box and guides are fixed directly onto the wall outside the window frame.
This is suitable for all window and door openings. However, your window/door frames or handles extend beyond the wall you will need to use packers (link) when fixing your modern roller shutters.
Mounted in the window reveal
With this mounting method, the header box and guide rails are mounted inside the external window reveal/recess.
This method requires precise measurements as there is no room for error. To mount the modern roller shutter in the recess you will require a recess depth of at least 40mm.
If your windows open outwards such as casement, awning or hopper windows it is recommended that you choose the on wall mounting method as the guide rails mounted inside the window recess could interfere with the operation of the window.
Mounted in the window reveal
With this mounting method, the header box and guide rails are mounted inside the external window reveal/recess.
This method requires precise measurements as there is no room for error. To mount the modern roller shutter in the recess you will require a recess depth of at least 40mm.
If your windows open outwards such as casement, awning or hopper windows it is recommended that you choose the on wall mounting method as the guide rails mounted inside the window recess could interfere with the operation of the window.
Roller Shutter Guides
Control types
Your DIY roller shutters can have either a manual or automated control.
The quickest and easiest method to operate roller shutters is by choosing one of our automated options which are battery-operated or electric. Our electric roller shutters need to be hardwired and require the services of a professional electrician.
Manual cord and winder
Whilst our manual roller shutters are the most cost-effective type of roller shutter, they are by far the most difficult to install.
Our manual wind roller shutters are supplied with a cord that acts similar to the cord on a roller blind, however, due to the weight of the roller shutters, the cord needs to be wound using a crank handle on a wall-mounted winder.
Manual spring-loaded and key lock
Each shutter is manufactured with a pre-tensioned spring tailored to the weight of the shutters to ensure a smooth gliding action. All spring-loaded shutters need to be key-locked.
They are ideal for serveries and garage door-type applications, however, they need to be operated from the front, so if they are on exterior windows they would need to be operated from the exterior of the building.
Manual spring-loaded and key lock
Each shutter is manufactured with a pre-tensioned spring tailored to the weight of the shutters to ensure a smooth gliding action. All spring-loaded shutters need to be key-locked.
They are ideal for serveries and garage door-type applications, however, they need to be operated from the front, so if they are on exterior windows they would need to be operated from the exterior of the building.
Battery operated Roller Shutters
By far the simplest and easiest method for DIY shutter installation is our battery-operated control systems. All Shutters4U products – Domestic, Bush Fire, Cyclone and Commercial roller shutters Adelaide have the same choice of controls.
Our battery-operated roller shutters are a simple DIY installation and do not require the services of a qualified electrician. And being battery powered your modern roller shutters will be operable in the event of a power outage.
Battery operated roller shutters are operated via a wall-mounted controller, but you can also upgrade to have an additional handheld remote control. The handheld remote control unit will control up to 9 different shutters and works in conjunction with the wall-mounted controller. Hence you will always need a wall-mounted controller even when using a remote control.
When upgrading to a handheld remote control please ensure that you select the battery controller for use with the handheld remote control. Handheld remote controls are ordered separately from the ‘Extras’ menu on the ordering page.
Wall-mounted control unit
All battery-powered control units are wall-mounted. Sleek and elegant they fit nicely onto the wall
and sit in a special dock.
The lithium-ion battery can be charged directly from the base of the docking station if there is a plug point located nearby or alternatively the unit can be removed from the dock and charged at your nearest powerpoint.
Hand-held remote control
For the ultimate ease and convenience, you can operate your modern roller shutters using a handheld remote control. Shutters4U hand-held remote-control unit for the working of rollers shutters in Adelaide operates using works using radio frequency technology and can be used to control up to a total of 9 different shutters from the comfort of your chair.
Hand-held remote control
For the ultimate ease and convenience, you can operate your modern roller shutters using a handheld remote control. Shutters4U hand-held remote-control unit for the working of rollers shutters in Adelaide operates using works using radio frequency technology and can be used to control up to a total of 9 different shutters from the comfort of your chair.
Electric powered (hardwired) Roller Shutters
Shutters4U electric (mains) operated roller shutters can be controlled via a wall-mounted switch or by remote control. If you have a handheld remote control you do not need a wall-mounted switch.
Electric wall-mounted switch
Electric roller shutters are quick and simple to operate using a wall-mounted switch. Simply press the button for up, down or anywhere in between.
Electric hand-held remote control
The operation of your electric roller shutters can be made even easier with the use of a handheld remote control. Shutters4U remote control option allows you the convenience of operating up to 16 different shutters from one controller. Adding remote control to your shutters can be of great benefit to the elderly or anyone who has mobility issues as they enable you to operate your modern roller shutters from the comfort of your armchair from any room within the house.
Electric hand-held remote control
The operation of your electric roller shutters can be made even easier with the use of a handheld remote control. Shutters4U remote control option allows you the convenience of operating up to 16 different shutters from one controller. Adding remote control to your shutters can be of great benefit to the elderly or anyone who has mobility issues as they enable you to operate your modern roller shutters from the comfort of your armchair from any room within the house.
Next Step
Now that you know what the parts of a Roller Shutter are, let’s move on to the next step.
If you still have any questions, please give us a call or send us a message
Frequently Asked Questions
Roller Shutters
What are roller shutters?
Roller shutters are a type of window or door covering that consists of horizontal slats or panels hinged together. These slats are typically made of aluminium or steel, although other materials like PVC or wood may also be used. The shutters are mounted above the window or door opening and can be manually or motor-operated.
What are the advantages of roller shutters?
Overall, roller shutters offer a range of advantages for your home, including enhanced security, privacy, light and noise control, energy efficiency, weather protection, and ease of maintenance. They can be a valuable addition to any property, providing numerous benefits to you and your loved ones.
Can roller shutters make a room completely dark?
Roller shutters can significantly reduce the amount of light entering a room. Keep in mind that the darkness level will depend on various factors like the material and design of the shutters, the installation method, and if there are any gaps or light leaks around the edges.
Are roller shutters secure?
Nowadays roller shutters are considered one of the most secure options for windows and door coverings. That’s because of the extra layer of protection that makes it more difficult for intruders to gain access to your home or commercial property.
However, to keep your home safe with roller shutters, we always suggest ensuring proper installation, regular maintenance, and use of other security measures in combination with security roller shutters, such as alarms, motion sensors, and reinforced entry points, to enhance the overall security of your property.
Do roller shutters provide insulation for your home?
Yes, roller shutters can provide insulation for your home and contribute to energy efficiency as they act as an additional insulating layer on windows and doors. In fact, in colder seasons, roller shutters can help retain heat inside the house, while in hot weather, they can block out heat from entering.
By investing in high-quality roller shutters from shutters4u, you can boost their insulation properties and enjoy the benefits of improved energy efficiency and indoor comfort.
How to clean roller shutters at home?
Cleaning roller shutters at home is an easy process. All you need to do is to wash them with soft soap and scrub them with a sponge or microfibre cloth. Before that, ensure the shutters are closed to clean their interior and exterior. Also, first, remove any debris or dust from their surface.
Remember, regular cleaning and maintenance of roller shutters will help keep them in good condition and prolong their lifespan.
Where can be roller shutters installed?
The versatility and customizable nature of roller shutters make them suitable for various applications, and they can be tailored to fit your specific needs and requirements. Just to mention some examples, roller shutters are usually installed in windows, doors, shopfronts, warehouses, industrial buildings and more.
What roller shutter colours are available in shutters4u?
We have a brilliant colour palette available for shutters in Australia, starting from the classics to the ones that deck up pretty well with your space. Our team also offers customization in terms of colours and brings different combinations for your home or business space. You name it, and we provide it.
If you need ideas for what colours will match your home then give us a call, and we will be happy to suggest the best colour options for you.
How to install DIY roller shutters?
Installation instructions for your DIY roller shutters are available in a detailed step-by-step video as soon as your order is placed. In your order, you will receive a link to a set of videos with instructions on how to install your shutters.
We have a separate video for motorised and manual roller shutter installation, so no matter what you choose you have everything you need to be able to install the shutters yourself with no issues.
Still not sure if DIY Roller Shutters are for you?
We got you covered! We can suggest a group of experienced roller shutter installers who can complete the job for you, ensuring a high-quality finish at great prices. They offer roller shutters in Adelaide, roller shutters in Perth, roller shutters in Sydney, roller shutters in Brisbane and more.
Roller Blinds
What are roller blinds?
Roller blinds are a type of window covering made from a single piece of fabric or other flexible material that can be rolled up or down to cover or uncover a window. They are commonly used in residential and commercial spaces to control the amount of light entering a room and provide privacy.
Roller blinds are known for their simplicity, functionality, and versatility.
They are easy to install and operate, making them a popular choice for window coverings in homes, offices, and other spaces. They provide a clean and streamlined look when fully rolled up and can be adjusted to different positions to allow for varying levels of light and privacy.
What are dual roller blinds?
Double roller blinds are popular for their versatility, offering a practical and stylish solution for controlling light and privacy in residential and commercial spaces. They are a type of window covering that combines two different types of fabrics on a single roller system. They offer the ability to switch between two different levels of light control and privacy, providing versatile functionality and aesthetic options.
What are the benefits of DIY roller blinds?
One of the primary advantages of DIY roller blinds is the potential for cost savings, you can avoid paying for professional installation or custom-made blinds, which can be more expensive. Additionally, they allow you to have full control over the design and customization according to your specific window measurements.
Moreover, an additional benefit of DIY roller blinds is that they are easy to keep clean and maintain.
Fabric options for roller blinds
Depending on the needs you have for each room, there are different fabric options for roller blinds DIY:
- Polyester
- PVC
- Vinyl
Operating system options for roller blinds?
Roller blinds can be operated using various systems, depending on your preferences and requirements. Here are some common operating systems for DIY roller blinds for windows:
- Manual Chain or Cord: This is the most traditional operating system for roller blinds. It involves a chain or cord attached to the blind that allows you to pull up or down the blind to your desired position.
- Spring-Loaded Mechanism: Spring-loaded roller blinds utilize a spring mechanism within the roller tube. These blinds can be easily operated by gently pulling down on the bottom of the blind to lower it and releasing it to allow the spring to retract and raise the blind. This system does not require chains or cords, providing a clean and elegant look.
- Automated: Motorised roller blinds have a motor that allows you to control the blinds using a remote control, wall switch, or even a smartphone app. Motorized blinds are particularly beneficial for hard-to-reach windows or for individuals with mobility issues.
- Smart Home Integration: Some roller blinds can be integrated into smart home systems, such as Amazon Alexa, Google Home, or Apple HomeKit. This allows you to control the blinds using voice commands or through smartphone apps.
Do roller blinds provide insulation for your home?
Roller blinds can provide some level of insulation for your home, depending on the type of fabric or material used. In fact, roller blinds can contribute to energy efficiency and temperature control. During hot weather, using roller blinds with light-coloured or reflective fabrics can help reflect sunlight and reduce solar heat gain, keeping your space cooler. In colder months, using roller blinds made from thicker or insulating materials can help prevent heat loss and improve thermal efficiency.
How to clean roller blinds?
It is important to clean and maintain the roller blinds regularly to ensure they will last for longer.
In this case, there are two easy ways to clean internal roller blinds, either by wiping them down with a damp, soft cloth or vacuuming them.
Where can Roller blinds be installed?
DIY roller blinds can be installed in any residential and commercial space where you have good ventilation. Roller blinds offer a versatile and space-saving solution for controlling light, privacy, and temperature in any room.
However, It's important to consider the specific requirements of the installation location, such as the size of the windows or doors, the mounting options available, and any special considerations for the type of blind chosen.
How to install roller blinds?
Installation instructions for your DIY roller blinds are available in a detailed step-by-step video as soon as your order is placed. In your order, you will receive a link to a set of videos with instructions on how to install your shutters.
We have a separate video for motorised and manual roller blinds installation, so no matter what you choose you have everything you need to be able to install the shutters yourself with no issues.
Still not sure if DIY Roller Blinds are for you?
We got you covered! We can suggest a group of experienced roller blind installers who can complete the job for you, ensuring a high-quality finish at great prices. They offer roller blinds in Adelaide and roller blinds in Perth.
